Used to automatically switch power supply from mains to generator during power failures, ensuring uninterrupted electricity.
Our AMF panels are designed to provide seamless power transfer between the main supply and standby generators. In the event of a mains power failure, the panel automatically starts the generator and shifts the load, ensuring uninterrupted power supply. Once the mains power is restored, the panel safely transfers the load back and shuts down the generator. Widely used in industries, hospitals, data centers, commercial complexes, and residential facilities, AMF panels guarantee reliable power management with minimal human intervention.
Key Features
-
Automatic changeover between mains and generator
-
Quick response to mains failure for uninterrupted power
-
Generator auto start/stop with safe load transfer
-
Digital monitoring of voltage, current, and frequency
-
Protection against under/over voltage and short circuits
-
Compact and modular design for easy installation and maintenance
Technical Specifications
| Parameter |
Specification |
| Voltage Rating |
230V / 415V AC |
| Current Rating |
Up to 6300A |
| Frequency |
50/60Hz |
| Enclosure Type |
IP31 to IP65 |
| Busbar Material |
Copper or Aluminum |
| Standards |
IEC 61439, IS 8623 |
